ZENIX LEN-2

Scan, sense, and connect with confidence. The ZENIX LEN-2 is a high-performance BLE scanner locator and gateway, designed for real-time data collection and beacon positioning. With POE and Wi-Fi connectivity, extended indoor range via external antenna, and seamless integration across smart buildings, healthcare, and industrial spaces, LEN-2 brings precision and scalability to your environment.

Brand: Sentrax
Model: ZENIX LEN-2

Click here to get a quote.

Or click here to talk to a live specialist

Category: Brand:

Features

  • BLE filtering (Sentrax’s Proprietary Algorithm)
  • Environmental Sensing and Motion Detection
  • Beacon PDU Extraction
  • Remote Tag Devices Configuration & Update

Operating Environment

  • Temperature Range 0°C to 60°C
  • Operating Humidity 90%

Sensors and Interfaces

  • Temperature Sensing 0 – 65°C
  • Humidity Sensing 0 – 100 %RH
  • Pressure Sensing 0.3 – 1.2 bar
  • Light Sensing 1 – 65535 lux
  • PIR Motion Sensing 100° deg
  • TVOC Sensing 1 – 500 VOC
  • Point
  • Button 1 User button
  • Power LED 1 Red LED
  • Status LED 1 Green LED

Enclosure

  • Type: BLE 5.2 Scanner
  • Material: ABS
  • Dimensions: 125 mm x 125 mm x 29 mm
  • Protection Class: IP54
  • Colour: Off-white
  • Weight: 166g
  • Antenna Type: Internal

Description

ZENIX represents a series of cutting-edge locator and gateway systems, leveraging advanced IoT hardware and software platforms to facilitate sensing and communication across Smart Building, Healthcare, and Industrial sectors. The ZENIX LEN-2 is specifically designed to collect data through beacon scanning, offering real-time sensor data and position information for beacons within its proximity.

Operating as a BLE Scanner Locator with POE and Wi-Fi interfaces, the ZENIX LEN-2 scans beacons using its external antenna to gather data. It delivers real-time sensor data and position information for nearby beacons, with the external antenna extending the indoor range.

Powered by an embedded processor equipped with Sentrax’s advanced BLE scanning firmware, the ZENIX LEN-2 ensures high-performance scanning capabilities. Additionally, it features an effortless wall/ceiling mount system for convenient installation

Application Area:

  • Indoor localization
  • Indoor navigation
  • Location-based services
  • Asset & Logistics
  • Tracking
