ZENIX LON-2

Install and locate with precision. The ZENIX LON-2 is a smart AoA indoor locator and gateway with sub-meter accuracy, real-time tracking, edge processing, and seamless integration into intelligent environments.

Brand: Sentrax
Model: ZENIX LON-2

Click here to get a quote.

Or click here to talk to a live specialist

Category: Brand:

Features

  • AoA filtering (Sentrax’s Proprietary Algorithm)
  • Beacon Above/Below detection
  • Beacon PDU Extraction
  • Remote tag device configuration & update

Operating Environment

  • Temperature Range: 0°C to 60°C
  • Operating Humidity: 90%

Sensors and Interfaces

  • Azimuth Angle: 0 – 359 deg (± 5 deg)
  • Elevation Angle: 0 – 90 deg (± 5 deg)
  • Temp: (int.) 0 – 65°C
  • Button: 1 user reset button
  • LED: 2 Red LEDs and 2 Green LEDs

Enclosure

  • Type: BLE 5.1 AoA Scanner
  • Dimensions: 240 mm (W) x 240 mm (L) x 60mm (H)
  • Protection Class: IP40
  • Material: ABS UL94V-0
  • Colour: Off-White
  • Weight: 625g

Description

The ZENIX LON-2 is a sophisticated indoor locator and gateway system that utilizes Angle of Arrival technology for precise tracking. It is part of Sentrax’s ZENIX BLE Scanners family, providing real-time location information for assets and individuals.

The Sentrax’s Angle of Arrival (AoA) Scanner, by scanning and detecting Sentrax’s PINIX
(AoA) Beacons, collects data, provides real-time angle information, and runs an edge computation algorithm that provides fast & precise computation and makes installation easy. This allows for cost-effective and intelligent workplace solutions.

The ZENIX LON-2, equipped with cutting-edge IoT hardware and software, is designed to serve various industries such as smart buildings and healthcare. It provides a complete solution for real-time location and positioning with sub-meter accuracy.

Application Area:

  • Indoor localization
  • Persons Positioning
  • Location-based services
  • Asset & Logistics Tracking
